For an up to date list of tooling, please contact: sales@telecomconnections.ltd.uk.
Expand the sections below to see the tooling we have from Molex, Hirose, JAE, AMP, Toby, Harwin, JST, EDAC, ITT, FCI, Cinch and Souriau.
Telecom Connections have a wide range of application tooling.
Molex
| Terminal | AWG | Comments |
|---|---|---|
| 50058 | 28-32 | 1.25mm Single Row Female |
| 50079 | 26-28 | 1.25mm Single Row Female |
| 50061 | 28-32 | 1.25mm Board In |
| 50516 | 28-32 | 1.25mm Dual Row |
| 50125 / 50133 | 28-32 | 1.25mm Single Row Male |
| 50641 | 28-30 | 1.25mm Panelmate |
| 1854 / 1855 | 24-28 | 1.57mm Pin Socket System |
| 2189 / 2190 | 24-28 | 1.57mm Pin Socket System |
| 4559 | 24-28 | 1.57mm Pin Socket System |
| 1560 / 1561 | 18-24 | 1.57mm Pin Socket System |
| 1854 / 1855 | 24-30 | 1.57mm Pin Socket System |
| 1433 / 1434 | 24-30 | 2.36mm Pin Socket System |
| 1189 / 1190 | 14-20 | 2.36mm Pin Socket System |
| 50011 | 24-30 | 2.0mm Micro Blade |
| 50394 | 26-30 | 2.0mm Milli Grid |
| 43030 / 43031 | 20-24 | Micro-Fit 3 |
| 5556 / 5558 | 18-24 | Mini-Fit |
| 44476 / 44478 | 18-24 | Mini-Fit HCS |
| 5263 | 22-28 | 2.5mm SPOX |
| 50802 | 22-28 | 2.5mm SPOX |
| 5194 | 18-24 | 3.96mm SPOX |
| 4809 | 22-30 | 2.54mm KK |
| 2478 | 18-24 | 3.96mm Maxi KK |
| 70058 / 71851 | 24-30 | C-Grid SL Tool 69037-1148 |
| 70021 | 24-30 | C-Grid SL Pin |
| 90119 | 22-24 | C-Grid III Tool 69037-1017 |
| 90119 | 26-28 | C-Grid III Tool 69037-1018 |
| 501334(T) / 501193(G) | 28-32 | 1mm Picoclasp / 2mm Illumimate |
| 87421 | 24-30 | 1.5mm Pico SPOX |
| 43375 | 14-18 | 7.50mm SABRE |
| 50012 / 50013 | 24-28 | 2.00mm Wire To Wire Plug / Socket |
| 50147 / 50148 | 20-22 | 2.5mm Mizu-P25 |
| 50212 | 24-30 | 2.00mm Sherlock |
| 56134 | 22-28 | 2.00mm MicroClasp |
| 502381 | 26-28 | 1.25mm CLIK-Mate |
| 502438 | 22-26 | 2.00mm CLIK-Mate |
| 172160 | 18-20 | 3.96 Edge Mate |
| 172253 | 16-18 | 2.5mm Ultra-fit |
| Picoflex | 28 | Ribbon Connectors |
| 172063 | 12-16 | 5.7mm Mega-fit |
| 501334(T)/501193(G) | 28-32 | 1mm Pico-Clasp 2mm IllumiMate |
| 50058/50079 | 26-32 | 1.25mm Single row PicoBlade Female |
| 50123/50133 | 28-32 | 1.25mm Single row PicoBlade Male |
| 50061 | 28-32 | 1.25mm Board In 51022 housing |
| 50516 | 28-32 | 1.25mm Dual row Pico-Gold |
| 50641 | 28-30 | 1.25mm PanelMate |
| 502381 | 26-28 | 1.25mm CLIK-Mate |
| 502438 | 22-26 | 2.00mm CLIK-Mate |
| 87421 | 24–30 | 1.5mm Pico Spox |
| 50112/50113 | 24-28 | 2.00mm Disconnectable MiII |
| 50212 | 24-30 | 2.00mm SherLock |
| 56134 | 22-28 | 2.00mm MicroClasp |
| 50394 | 26-30 | 2.00mm MilliGrid |
| 50011 | 24-30 | 2.00mm MicroBlade |
| 5263 | 22-28 | 2.5mm Spox |
| 50802 | 22-28 | 2.5mm Wire to Board 51191 Housing |
| 172253 | 16-18 | 2.5mm UltraFit |
| 50147/50148 | 20-22 | 2.5mm Splashproof 52266/52213 Housings |
| 4809 | 22-30 | 2.54mm KK |
| 70058/71851/70021 | 24-30 | 2.54mm C-Grid SL |
| 90119 | 22-28 | 2.54mm C-Grid III |
| 1854/1855/2189/2190/4559 | 24-30 | 1.57mm Pin/Socket System |
| 1560/1561 | 18-24 | 1.57mm Pin/Socket System |
| 1433/1434 | 24-30 | 2.36mm Pin/Socket System |
| 1189/1190 | 14-20 | 2.36mm Pin/Socket System |
| 43030/43031 | 20-24 | 3.00mm Micro-Fit 3 |
| 2478 | 18-24 | 3.96mm Maxi KK |
| 5194 | 18-24 | 3.96mm Spox |
| 172160 | 18-20 | 3.96mm Edge-Mate |
| 5556/5558 | 18-24 | 4.20mm Mini-Fit |
| 44476/44478 | 18-24 | 4.20mm Mini-Fit HCS |
| 172063 | 12-16 | 5.7mm Mega-Fit |
| 43375 | 14-18 | 7.50mm Sabre |
| 90327 | 26-28 | 1.27mm Picoflex Ribbon Connector |
| 70625/70127/70625 | 26-28 | MX-50 IDC Ribbon Connector |
| 5320/90635/5360 | 26-28 | QF-50 IDC Ribbon Connector |
Hirose
| Terminal | AWG | Comments |
|---|---|---|
| A3B | 26-30 | 2mm Dual Row |
| DF1B | 24-28 | 2.5mm Pitch |
| DF3 | 24-28 | 2mm Single Row |
| DF4 | 24-28 | 2mm Pitch Wire To Board |
| DF9M | 28 | 31 Way & 41 Way Flat Panel Display Interface Connectors |
| DF11 | 24-28 | 2mm Dual Row |
| DF13 | 26-30 | 1.25mm Single & Dual Row |
| DF14 | 26-30 | 1.25mm Low Profile |
| DF19 | 28-30 | 1mm Low Profile |
| DF20 | 28-32 | 1mm Dual Row |
| DF57 | 28-30 | 1.2mm Pitch Low Profile |
| HR10 / HR10A | 26-30 | Panel Mounting / Cable Wiring Circular Connector Series |
| HR30 | 26-30 | Panel Mounting / Cable Wiring Circular Connector Series |
JAE
| Terminal | AWG | Comments |
|---|---|---|
| LZ | 28-32 | 1.25mm Low Profile |
| LY | 26-30 | 2mm Dual Row |
| IL-S | 24-28 | 2mm Single Row |
| IL-G | 22-28 | 2.5mm Single Row |
| IL-AG5 | 20-22 | Molex 2.3mm Hand Tool |
| FI-X | 30-36 | 1mm Single Row |
| FI-E | 30-36 | 1mm Single Row |
| FI-R | 30-36 | 0.5mm Single Row |
| FI | 28-32 | 1.25mm Single & Dual Row |
| MX19 | 20-22 | Male Female Waterproof |
AMP
| Terminal | AWG | Comments |
|---|---|---|
| 63381-1 | 18-22 | 3.18mm Receptacle |
| HE14 | 24-28 | HE14 2.54mm Single Row |
| 170262-1 | 20-26 | AMP EI 2.5mm Pitch Polarised |
| 171610-1 | 22-26 | ULTREX 2.5 & 2.54mm Dual / Single Row |
| 350566-1 | 18-22 | Mini Board-In ( Mini AMP In ) |
| 350566-7 | 18-22 | Mini Board-In ( Mini AMP In ) |
| 925819-3 | 22-26 | Mini Board In ( Mini AMP In ) |
| 179609-1 | 26-30 | 2.00mm AMP CT |
| 163300-6 | 14-20 | AMP Mate ′N′ Lock |
| 794606-1 | 20-24 | AMP Micro Mate ′N′ Lock |
| AMP HDP20 | 22-26 | PP3 Pin Socket D-Type |
| AMPLIMITE HDP22 | 22-28 | PP3 Pin Socket Hight Density D-Type |
| AMP Modu | 22-26 | PP3 Stripper Crimper |
| AMP Modu | 27-32 | AMP Modu |
| Micromatch | 28 | Ribbon Connectors |
| Ansley | 28 | IDC Connectors |
| AMP Latch | 28 | IDC Connectors |
Toby
| Terminal | AWG | Comments |
|---|---|---|
| PD200T-020 | 26-30 | 2mm Single / Dual Row |
| AM254 | 22-30 | 2.54 mm Molex KK Copy |
Harwin
| Terminal | AWG | Comments |
|---|---|---|
| M20 | 22-30 | 2.54mm Dual Row : No Centre Bump |
| M22 | 24-30 | 2mm Single Row |
| M22-307 | 24-30 | 2mm Single Row |
| M22 | 24-30 | 2mm Dual Row : No Centre Bump |
| M30 | 26-30 | 1.25mm Single & Dual Row |
| M40 | 28-32 | 1mm Single & Dual Row |
| M80 | 22-28 | Datamate |
JST
| Terminal | AWG | Comments |
|---|---|---|
| SSH | 28-32 | 1mm Single & Dual Row |
| SSHL | 28-32 | 1mm Single & Dual Row |
| SZN | 28-30 | 1.5mm Board In |
| SZH | 28-32 | 1.5mm Single Row |
| SZPD | 24-28 | 1.5mm Secure Lock Dual Row |
| SPH | 24-30 | 2mm Single Row |
| SPHD | 22-28 | 2mm Single & Dual Row |
| SAN | 24-30 | 2mm Board In |
| SXH | 22-28 | 2.5mm Single Row |
| SVH-21 | 18-22 | 3.96mm or 5mm Single Row |
| SVH-41 | 16-20 | 3.96mm or 5mm Single Row |
| SXF | 20-26 | 5mm Dual Row |
| SCN | 18-22 | 2.5mm Board In |
| SEH | 22-30 | 2.5mm Single Row Low Profile |
| SHF | 22-28 | 2.5mm Disconnectable |
| SMM | 28-32 | 1.5mm Disconnectable |
| SLM / SLF | 20-26 | 4.5mm Disconnectable |
| STB | 26-28 | Push-On |
| SSL-O.8-3BT | 24-28 | 3mm Fork Tag |
| STO-1.0 | 18-20 | 110 Push-On ( 0.5mm or 0.8mm Tab ) |
| STO-1.0 | 18-20 | 187 Push-On ( 0.5mm or 0.8mm Tab ) |
| STO-21 | 18-22 | 250N Push-On |
| STO-61 | 14-18 | 250N Push-On |
| SRA-20 | 18-22 | Ring Tag Without Strain Relief 2.5mm 3.2mm |
EDAC
| Terminal | AWG | Comments |
|---|---|---|
| 516 | 16-28 | Rack and Panel system |
| 520 | 16-28 | 5.08mm Disconnectable Power connectors |
| 566 | 22-28 | 2.00mm Disconnectable IP67 Waterproof |
| 565 | 22-28 | 2.50mm Disconnectable IP67 Waterproof |
| 567 | 14-22 | 5.00mm x 5.9mm Disconnectable IP52 Splashproof |
| 570 | 14-22 | 5.80mm Disconnectable IP67 Waterproof |
| 568 | 14-22 | 1 position Disconnectable IP67 Waterproof |
ITT
| Terminal | AWG | Comments |
|---|---|---|
| Trident | 16-20 | Pin |
FCI
| Terminal | AWG | Comments |
|---|---|---|
| Minitek | 26-30 | 2mm dual row |
| Dubox | 22-30 | 2.54mm single/dual row |
| Bergcon | 22-26 | 2.54mm single/dual row |
| Quickie | 28 | IDC connectors |
Cinch
| Terminal | AWG | Comments |
|---|---|---|
| D-Type | 26-30 | Male & Female |
| D-Type | 20-24 | Male & Female |
Souriau
| Terminal | AWG | Comments |
|---|---|---|
| CM24 | 24 | Pin & Socket |
| CM20 | 20 | Pin & Socket |
Harting
| TERMINAL | AWG | COMMENTS |
|---|---|---|
| 0918 | 28 | IDC Connectors |
Deutsch
| TERMINAL | AWG | COMMENTS |
|---|---|---|
| Deutsch | 14-20 | DT Waterproof |
